> Replacement DIsplay Control Board for Gottlieb Pinball Machines
Display Control Board for Gottlieb System 3
Replacement A8 Control Board for Gottlieb Premier Pinball Machines.


Upgrade your machine now!

System 3 A1 Control Board
Status: Available
$229.00
See our ebay Store to order these and other products.

eBay Store: bostonpinballcompany
Free Shipping to US customers, outside US we will send a shipping quote after your order.
Also see our Ebay Store or Email us

Used in the following System 3 Gottlieb Pinball Machines:


Barb Wire, Cue Ball Wizard, Frank Thomas' Big Hurt™, Freddy A Nightmare on Elm Street, Gladiators, Mario Andretti, Rescue 911, Shaq Attaq, Stargate, Street Fighter II, Super Mario Bros., Super Mario Bros. Mushroom World, Tee'd Off, Waterworld, Wipe Out, World Challenge Soccer



Replaces original Part Number MA1739

Design Information

The installation of the new A8 control board takes about 10 minutes. DOES NOT include Game DSPROM, you must use to original one or get a new one.

New features and improvements:

Very efficient HV Power Supply Section, completely new design.
Adjustable anode voltage for the Gas Tube DMD displays.
Ground connection point, test points.
IC Sockets for easy repair and replacement of IC chips.
All new capacitors, capacitors are known to degrade over time.

Put a new heart into your machine so it runs for many more years!!!

All new components, not 30 years old! Today's components are higher quality and more reliable. These new boards will last a lot longer than old reconditioned, retested, removed from old machines, or new old stock boards.

Extra ground wire connection, the old Gottlieb boards did not have a very good ground scheme, we have added the additional ground that is needed to connect to chassis ground. This provides additional protection and stability.

Classic look and feel of the original design, but with an new style and reliability. Components have the same reference numbers as the original boards, so the old schematics can be used for troubleshooting. (just a few minor changes)
